UV-2000 Ultraviolet Transmittance Analyzer
Rapidly measure diffuse transmittance in the ultraviolet wavelength region from 250 – 450 nm and comply with industry standards for in-vitro sunscreen analysis and textile UPF analysis.
Quickly Determine:
· In-vitro SPF | · UPF |
· UVA PF | · Broad Spectrum |
· Critical Wavelength | · UVA I/UV |
· UVA/UVB | · UVA & UVB Blocking |
· Star Rating | · and more … |
The UV-2000 is an industry leading UV transmittance analyzer counted on by leading cosmetic and textile manufacturers the world over. Driven by rapidly evolving industry requirements to simplify research and development or quality control for textiles and sunscreens, the UV-2000 is designed to comply with recently approved testing methods and delivers a hassle-free analytical experience.
![uv analyzer](https://www.labsphere.com/wp-content/uploads/2021/09/UV2000Fcloseup-1024x854.jpg)
Fast and Reliable
Achieve accurate scan results in less than 5 seconds. Our Spectralon® integrating sphere incorporates a xenon flash lamp to provide exceptional diffuse illumination of the product sample and minimize data integration time. New high performance diode array spectrometers coupled with advanced fiber optics are optimized for low stray light with superior wavelength stability and flash-to-flash repeatability.
![uv transmittance beach example](https://www.labsphere.com/wp-content/uploads/2021/09/SunscreenBeachScene-1024x768.jpg)
Ideal R&D and Production Testing
With its compact benchtop footprint and minimal upkeep, the UV-2000 is ideal for both R&D and production QA/QC testing. The UV-2000 enables rapid testing to the approved in-vitro sunscreen and UPF textile methods such as COLIPA UVA-PF, ISO 24443, Boots Star Rating, and US FDA for in-vitro sunscreen, and AS/NZS 4399, EN 13758, AATCC 183, GB/T18830, Japan Garment Association Standard and Japanese Industrial Standards (JIS) for textile analysis.
UV Transmittance Analyzer Specifications
Whether you’re developing sunscreens and UV blocking filters for cosmetics, or textile products for UPF protection, the UV-2000 is right for you.
UV-2000S
- Order Number AA-00909-000
- UV-2000S Starter Kit AS-02796-000
- HelioScreen HD6 Plates HelioScreen HD6 Plates
- Wavelength Range 250 to 450 nm
- Wavelength Accuracy ±1 nm
- Bandwidth (FWHM) < 4 nm
- Wavelength Step (Data Interval) 1 nm
- Integrating Sphere Port Area < 5%
- Sample Exposure Area 0.79 cm2
- Lamp Xenon Flash Lamp
- UV Dose Per Measurement Cycle < 0.2 J/cm2
- Transmittance 0 - 100%
- Absorbance 0 - 2.7 A (Dual Doped PMMA Method)
- SPF 1 - 50+
- Scan Time < 5 s
UV-2000F
- Order Number AA-00909-100
- Wavelength Range 250 to 450 nm
- Wavelength Accuracy ±1 nm
- Bandwidth (FWHM) < 4 nm
- Wavelength Step (Data Interval) 1 nm
- Integrating Sphere Port Area < 5%
- Sample Exposure Area 0.79 cm2
- Lamp Xenon Flash Lamp
- UV Dose Per Measurement Cycle < 0.2 J/cm2
- Transmittance 0 - 100%
- Absorbance 0 - 2.7 A (Dual Doped PMMA Method)
- UPF 1 - 50+
